Preparing for a Solar Panel Installation

Updated December 2016: With good preparation, a capable installer and with all the facts in hand, installing a solar panel system can be an enjoyable and very rewarding experience. As with any construction project the success and efficiency of a solar PV panel installation comes down to good planning. Some advice for potential system owners preparing for a new solar panel installation is below:

Back to Articles

Roof Mounted Solar PV Panel Installation

Connecting to the National Grid: Single phase solar PV systems under 3.68kWp in size (approx 12-20 panels) and three phase systems under 11kWp (40-60 solar panels) do not usually require advanced permission from the Distribution Network Operator (the power company which maintains the local mains power network) before connecting the solar PV system to the National Grid.

Systems bigger in size and multiple installations as may be the case with new builds will require permission from the DNO before systems can be connected. If prior approval is required, grid connection applications can take upwards of 65 days so the sooner the grid connection application is made in the planning & design process the better.

Solar PV Mains Connection Mains Electricity Suppliers: Installing a solar PV system and becoming an electricity generator will change the amount of mains electricity that you need to buy and the times you need to buy it. To avoid delays and complications, if it's found to be of benefit to change suppliers it is a good idea to change before the solar PV system is installed. Taking into account your new energy usage profile and the terms and conditions of the new agreement.
Ground Mounted Commercial Solar PV Panel Mounting System Planning Permission: Planning permission is sometimes required when installing larger systems or installing solar panels in sensitive areas such as within conservation areas. Gaining planning permission can be a lengthy process so it is advisable to find out any special requirements beforehand and make a pre-planning enquiry with the local authority early in the design & planning stage. More information about Planning Permission requirements for Solar Panels can be found here: Planning Permission for Solar Photovoltaic (PV) Systems.
Commercial Flat Roof Solar PV Panel Installation Building Regulations & Structures: For safety and to maintain the structural integrity of the building; solar panel installations needs to be installed in compliance with the building regulations, see building regulations for solar panels. It is also worth bearing in mind that solar panel systems can operate for a very long time (40 years plus). It is sensible to make sure that underlying structures such as roofing supports, roofing materials and any other support structures will also last for the lifetime of the solar PV system. This will avoid what could later prove to be costly and complicated repairs further down the line.

Top of page

Professional Solar PV System Design & Planning

The success of any renewable energy project is always in the quality and robustness of the system design, our experienced in-house design team has been designing innovative and ground breaking solar PV and other renewable energy systems since 2007.

Solar PV System Design
We take a collaborative and open approach and often find the very best systems are those where the system owner/developer has taken an active involvement with the design.

We can help prepare cost effective designs, roof layouts and documentation for all types and size of solar PV project; including drawings, bills of materials and detailed custom installation/owners manuals. We work with installers and developers as well as private clients and businesses, so if you need any technical information prepared then contact us, we have specialist knowledge and experience at your disposal, you will find us easy to work with and happy to help.

Solar PV System Design & Planning

Solar PV Equipment and Installation Kits

If we are supplying systems and equipment to Solar PV installers or for DIY solar installations, we are always happy to include system designs, testing and bespoke documentation as part of the package.

Solar PV Equipment Suppliers
This can include:
  • System Performance Statements
  • Line Drawings and Schematics
  • Roof Layouts
  • Grid Connection Documents
  • Solar Panel Testing and Records

Solar PV Systems & Equipment
